    Polyester Plain Woven Fabrics

    Introduction:

    The 2-shed and 3-shed plain fabric is mainly used in special lines of paper making industry, Such as paper pulps making, packing and liner cardboard making, etc. Aslo could be used in mining industry for sieving or conveyor belt, high density board making, food drying, sludge dehydration machine, Concentrate and other filtration industries.

    Features:

    This wire netting offers acid and alkali resistance, wear resistance, high temperature resistant, long service life.
    With smooth surface, good tensile strength and permeability.
    High heat transfer efficiency, for the user to save energy.
    Can be Installed easily.
    Stretchable fabric.

    Applications:

    Plain weaving polyester fabrics are mainly used for pulp and paper industry, fiber board factory, and coal mining equipment, food, medicine and other industries in the conveyor belt, building materials.

    Materials and Common Specifications:

    Warp:0.5 mm
    Weft :0.5mm
    Strenth:750/1800 N/cm
    Air Permeability: 10000/6500 m3/m2h
    Material:100% Polyester.
    Type: Mesh Fabric.
    Style: Plain.
    Technics: Woven.
    Width: 43/44", 0.6m-3.65m polyester mesh.
    Mesh opening: 25-1068um polyester mesh fabric.
    Feature:Anti-Static, Flame Retardant, Shrink-Resistant
    Yarn Count: Monofilament, 18-420mesh/inch polyester mesh fabric.
    Density: 5-50/cm
    Weight: 0.5-3.0kg/sqm, 20-350g/m2 polyester mesh fabric.
    Seam Types: spiral rings,steel-clip,pin joint.

    Types We Offfer:

    Double layer polyester plain woven paper making dryer mesh screen
    100% polyester plain woven marine grade mesh vinyl fabric
    vinyl coated woven polyester mesh fabric
    High density polyester mesh fabric plain woven for bags


    Polyester Plain Woven Fabrics

    Polyester Plain Woven Fabrics

    Polyester Plain Woven Fabrics





    Specification

    Type

    Filament diameter mm

    Density(root/cm)

    Tensile strength

    N/cm

    Weight

    Kg/m2

    Thickness

    mm

    Mesh

    Aperture

    mm

    Air

    Permeability

    m3/m2h

    CFM

    127Pa

    Open porosity

    Warp

    Weft

    Warp

    Weft

    surface

    joint

    021002

    1.0

    1.0

    2.85

    2.65

    1600

    650

    0.6

    1.85

    7.1*6.73

    2.5*2.77

    32000

    2000

    52.55

    031002

    1.0

    1.0

    3.2

    3.25

    1600

    650

    0.8

    1.86

    8.1*8.2

    2.12*2.07

    25600

    1600

    45.9

    03902

    0.9

    0.9

    3.9

    3.65

    1600

    650

    0.55

    1.7

    9.6*9.3

    1.66*1.83

    20000

    1250

    46.58

    05602

    0.6

    0.6

    5.9

    5.6

    1600

    650

    0.62

    1.1

    14.98*14.2

    1.09*1.18

    18000

    1125

    42.89

    05802

    0.8

    0.8

    5.1

    5.3

    1600

    650

    0.89

    1.48

    13*13.5

    1.16*1.08

    15840

    990

    34.09

    06652

    0.65

    0.65

    7.4

    6.8

    1600

    650

    0.65

    1.19

    18.8*17.3

    0.7*0.82

    14400

    1190

    28.96

    06802

    0.8

    0.8

    6.6

    6.5

    1600

    650

    0.85

    1.45

    16.8*16.5

    0.72*0.73

    11600

    725

    22.65

    06702

    0.7

    0.7

    7

    7

    1600

    650

    0.77

    1.3

    17.8*17.8

    0.72*0.72

    11000

    690

    26.01

    07802

    0.8

    0.8

    7.8

    7

    1600

    650

    1.1

    1.45

    20.3*18

    0.32*0.54

    5920

    370

    16.54

    09502

    0.5

    0.5

    9.7

    10.3

    1600

    650

    0.5

    0.9

    25*6.2

    0.53*0.47

    10100

    634

    24.97

    12502

    0.5

    0.5

    13.5

    8.5

    1600

    650

    0.63

    1.95

    34.3*21.6

    0.24*0.65

    6500

    6280

    18.68

    09452

    0.45

    0.45

    10

    8.6

    1600

    650

    0.45

    0.88

    25.4*21.8

    0.55*0.71

    15570

    970

    33.71

    08603

    0.5

    0.6

    9.4

    9

    1600

    650

    0.6

    0.15

    23.8*23.1

    0.56*0.51

    9000

    560

    24.38

    06803

    0.7

    0.8

    7

    5.5

    1600

    650

    0.75

    1.53

    17.8*14

    0.72*1.0

    16000

    1000

    28.56

    07803

    0.8

    0.8

    8

    8

    1600

    650

    1.15

    1.66

    20.3*20.3

    0.45*0.45

    9184

    574

    12.96

    07903

    0.8

    0.8

    7.6

    6.5

    1600

    650

    1.25

    1.76

    19.3*16.5

    0.51*0.63

    6400

    400

    16.26
